GreenVAC · GTS
GreenVac DX AHUs are engineered air handling solutions designed to provide efficient and reliable air conditioning for commercial, industrial, hospitality, healthcare, and other HVAC applications.
GreenVac DX AHUs are engineered air handling solutions designed to provide efficient and reliable air conditioning for commercial, industrial, hospitality, healthcare, and other HVAC applications.
The units use a Direct Expansion (DX) cooling coil connected to an external refrigerant condensing unit to cool and dehumidify the supply air. Each AHU can be configured according to the required airflow, cooling capacity, external static pressure, filtration level, and project requirements.
Hotels | Hospitals | Offices | Shopping Malls | Commercial Buildings | Industrial Facilities | Educational Buildings
GreenVac AHUs are manufactured and configured to provide reliable air conditioning, efficient airflow, and long-term operating performance, with each unit selected according to the specific requirements of the project.
| Nominal Airflow Range | 1000 ~ 65000 CFM |
| Configuration: | Double skin 25/50 mm thickness thermally insulated panels |
| Fan / Motor: | AMCA Certified High efficiency DWDI centrifugal fans Plug, EC motor-fan combinations with high efficiency IE-3 or IE-4 |
| Sandwich Panels: | Rockwool or PU Insulation |
| Profiles: | Aluminum |
| Coils: | Cu/Al, stainless steel, with coating on demand |
| Filter Type: | Pre / bag / hepa / carbon filters |
| Drain Pan: | Stainless steel 304 |
Submit your project requirements and our engineering team will prepare a detailed quotation within 48 hours — including unit selection, performance data, and indicative pricing.
